Technical specifications:

1.25 horsepower

Cooling output BTU 12,150

Energy rating: A

Heating output BTU 12,100

Cooling

Power consumption: 910W

Efficiency coefficient: 3.9COP

Heating

Power consumption: 960W

Efficiency coefficient: 3.88COP

More details

Supply voltage:

230/50/1 V/Hz/Ph

Pipe diameter between units:

"1/2" – "1/4"

Cable between units:

3X1.5+2X0.75

Thermal magnetic circuit breaker

10C

Air volume – indoor unit [CFM]

380

The data you need to know

3D Airflow –

Uniform air distribution throughout the room

7 FAN SPEEDS –

Seven internal fan speeds for ultra-quiet operation

AUTO –

Automatic switching from cooling to heating depending on room temperature conditions.

 AutoRestart –

Automatic return to last operating mode in the event of a power outage

BMS –

A dry contact that allows the air conditioner to be turned on and off at low voltage.

I Feel –

Adjusting the room temperature according to the location of the remote control.

QUIET FUNCTION –

Extremely quiet operation

Sleep –

Automatic change of temperature in cooling and heating during the night for comfort and a pleasant sleep.

Timer X3 –

Automatically turn on/off the air conditioner, according to a preset setting for up to three time periods in 24 hours.

Volume detector –

Starting or stopping the air conditioner by detecting the presence of a person in the room for significant electricity savings (optional, supplied separately)

Wall Command –

Possibility of operation also by the control unit on the wall. Optional

Hydrophilic coating –

Maintains the air conditioner for a long time.

Product dimensions

Indoor unit dimensions:

Depth: 20.9 cm

Height: 28.9 cm

Width: 84.5 cm

Outdoor unit dimensions:

Depth: 32 cm

Height: 54 cm

Width: 84.8 cm

Ceiling air conditioner model ALPHA PR
